數控焊接設備的出現，結束了鋼筋籠手工進行捆綁的操作方式。但是設備在使用過程中也是會出現問題的，接下來就讓小編簡單給大家介紹一下山東數控焊接設備常見八種不好的現象。

The appearance of numerical control welding equipment ended the manual binding of reinforcement cages. However, there will also be problems in the use of the equipment. Next, let Xiaobian briefly introduce eight common bad phenomena of Shandong CNC welding equipment.

1、當在作業時出現掉刀頭，可以慢慢的調節數控焊接設備的動刀感應開關進行直刀頭回到正常的位置。

1. When the cutter head falls off during operation, you can slowly adjust the knife moving induction switch of the CNC welding equipment until the cutter head returns to the normal position.

2、數控焊接設備的矯直輪調直法一般都是采用波浪形調直法，但波浪不可過大避免增加牽引阻力，造成牽引不動牽引輪打滑鋼筋斷裂。

2. The straightening method of the straightening wheel of the CNC welding equipment generally adopts the wave shape straightening method, but the wave must not be too large to avoid increasing the traction resistance, causing the traction wheel to slip and the reinforcement to break.

3、當機器出現跑絲現象時，應檢查下設備是否為壓滾簧過緊，滑道拉簧過松，或者有可能是滑道下邊拖絲鋼棍不到位，滑道不滑動等原因造成的。

3. In case of wire running of the machine, it is necessary to check whether the pressing roller spring of the lower equipment is too tight, the tension spring of the slide is too loose, or the wire pulling steel rod under the slide is not in place, and the slide does not slide.

4、鋼筋出筒后如頭往上翹，調節上邊一組輪適當往下壓，如果出筒之后鋼筋往下翹，調節下邊一組輪適當?shù)耐享?，使鋼筋出頭端呈水平狀態。

4. If the head of the steel bar is tilted upward after the barrel is pulled out, adjust the upper group of wheels to press down properly. If the steel bar is tilted downward after the barrel is pulled out, adjust the lower group of wheels to push up properly, so that the head end of the steel bar is horizontal.

5、在數控機床鋼棒材軋制焊機上對雙棒進行彎曲時，會出現彎曲心軸脫落的現象，使一組車輪的外輪拉直并向內壓緊，使雙棒緊貼在一起。當彎曲大型箍筋時，彎曲速度應相應減慢。

5. When the double bars are bent on the steel bar rolling welding machine of the numerical control machine tool, the bending mandrel will fall off, so that the outer wheels of a group of wheels are straightened and pressed inward, so that the double bars are closely together. When bending large stirrups, the bending speed shall be reduced accordingly.

6、當出現彎絲現象，可以調整下調直塊的角度，要和調直器，壓滾槽在一條直線上。

6. In case of wire bending, the angle of the straightening block can be adjusted to be in line with the straightener and the rolling groove.

7、數控焊接設備的彎曲芯軸的調節：調節起落架汽缸，使彎曲芯軸的上頂點與導線筒孔的下邊成水平或低導線筒孔下邊1-2mm。

7. Adjustment of bending mandrel of CNC welding equipment: adjust landing gear cylinder so that the upper apex of bending mandrel is horizontal or 1-2mm lower than the lower edge of wire barrel hole.

8、在彎曲的過程中出現斷絲現象。可以檢查看是否是刀退不回，送絲滾上的壓簧過松，材質不好等原因造成的。

8. Wire breakage occurs during bending. You can check whether it is caused by the failure of the knife to retract, the looseness of the pressure spring on the wire feeding roller, and the poor material.

以上是是小編介紹的數控焊接設備常見故障的維修方法的全部內容，希望能對您有所幫助，如果您還想了解其他方面的內容，歡迎來咨詢我們網站http://www.xfkjgs.com！

The above is all the contents of the maintenance methods of common faults of CNC welding equipment introduced by Xiaobian. I hope it can be helpful to you. If you still want to know more about other aspects, please come to our website http://www.xfkjgs.com ！
